Açıklama
- 1/1.7” 4K 12 Megapiksel (4000X3000) Cmos Sensör
- 4000×3000 @ 20fps
- 2 Lens Girisi (Motorize ve Varifokal)
- H.265/H264/MJPEG sıkıstırma özelligi
- 120dB True WDR
- Çift direkt ISCSI veri blok depolama, NAA, UNP
| IPC5681-L | ||
| Camera | ||
| Sensor | 1/1.7″ 12 Megapiksel 4K Ultra HD progressive scan CMOS | |
| Day/Night | Otomatik (ICR) / Renkli / Siyah / Beyaz | |
| Shutter | Otomatik/Manuel, 1/6~1/8000 s | |
| Min.Illumination | Renkli: 0. 03LUX/F1.2, B/W: 0.01LUX/F1.2 | |
| S/N | 55dB den fazla | |
| WDR | 120dB True WDR | |
| Lens Mount | C/CS | |
| DC-Iris | N/A | |
| Motor Zoom/focus | N/A | |
| Video | ||
| Max. Resolution | 12MP(4000X3000)/4MP/3MP/1080P(1920×1080)/1.3M(1280×960)/720P(1280× 720)/D1(704× 576/704× 480) /CIF(352× 288/352× 240) | |
| Video Compression | U-Code/H.265/H.264/MJPEG | |
| Frame Rate | 12MP(1~ 20fps) / 3MP/1080P/720P(1 ~ 30fps) | |
| 9:16 Corridor Mode | Destekler | |
| ROI | Destekler | |
| Defog | Destekler | |
| HLC | Destekler | |
| Video Streaming | Triple | |
| OSD | N/A | |
| Privacy Mask | En fazla 4 Alan | |
| Audio | ||
| Audio Compression | G.711a / G.711u/ AAC-LC | |
| Two-way audio | N/A | |
| Storage | ||
| Edge Storage | Micro SD, Max 128GB | |
| Network | ||
| Protocols | IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSPRTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour | |
| Compatible Integration | ONVIF Profile S | |
| Interface | ||
| Audio I/O | 1/1 kanal In/Out | |
| Alarm I/O | 1/1 Kanal Giriş/Çıkış | |
| Serial Port | 1 RS485 Çıkışı | |
| Network | RJ-45 (10/100Base-T) | |
| Video Output | 1 kanal, BNC(1.0Vp-p/75 ) | |
| General | ||
| Power | DC12V, PoE (802.3af) | |
| Güç Tüketimi: 8 W | ||
| Dimensions (L x W xH) | 151.50mm × 71mm× 65mm | |
| Weight | 0.48 kg | |
| Working Environment | -20°C~+60°C, daha az 95% RH | |
