Açıklama
- 1/3” 4 Megapiksel (2592X1520) Cmos Sensör
- Video Analiz
- 3.6 mm Sabit lens
- H.265 / H.264 / MJPEG sıkıstırma özelligi
- 120dB True WDR , Smart IR Teknolojisi
- IP67 standartı destegi
| Model | IPC2124SR3-DPF36 | |
| Camera | ||
| Sensor | 1/3″, 4.0 megapixel, progressive scan, CMOS | |
| Shutter | Otomatik/Manuel, 1/6~1/8000 s | |
| Lens | 3.6mm @F1.8; Angle of view: 87° | |
| Min. Illumination | Colour: 0.02 Lux (F1.8, AGC ON) 0 Lux with IR on | |
| Day/Night | IR-cut filter with auto switch (ICR) | |
| IR Range | Up to 30m (98 ft) IR range | |
| S/N | 55dB den fazla | |
| WDR | 120dB | |
| Video | ||
| Max. Resolution | 2592×1520 | |
| Video Compression | U-Code/H.265, H.264, MJPEG | |
| Frame Rate | 4MP (2592×1520): Max. 20 fps; 4MP (2560×1440): Max. 25 fps | |
| 3MP (2048×1520): Max. 30 fps; 1080P (1920×1080): Max. 30 fps | ||
| 9:16 Corridor Mode | Destekler | |
| ROI | Destekler | |
| Video Streaming | Triple | |
| OSD | Destekler | |
| Privacy Mask | 4 Bölge | |
| Smart | ||
| Behavior Detection | Intrusion, crossing line, motion detection | |
| Exception Detection | N/A | |
| Intelligent Identification | Face detection | |
| Statistical Analysis | People counting | |
| Audio | ||
| Audio Compression | N/A | |
| Two-way audio | N/A | |
| Storage | ||
| Edge Storage | N/A | |
| Network | ||
| Protocols | L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, SIP, 802.1x | |
| Compatible Integration | ONVIF, API | |
| Interface | ||
| Audio I/O | N/A | |
| Alarm I/O | N/A | |
| Network | 1 RJ45 10M/100M Base-TX Ethernet | |
| General | ||
| Power | 12 V DC, or PoE (IEEE802.3 af) | |
| Power consumption: Max 6.4 W | ||
| Material | N/A | |
| Dimensions (L × W × H) | 157.3 × 62.4 ×63 mm (6.2″ × 2.5″ × 2.5″) | |
| Weight | 0.45 Kg | |
| Working Environment | -35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 95% RH(non-condensing) | |
| Vandal Resistant | IP66 | |
| Ingress Protection | N/A | |
