Açıklama
- Day/night functionality
- Smart IR, up to 30 m (98 ft) IR distance
- 3D DNR (Digital Noise Reduction)
- ROI (Region of Interest)
- 9:16 corridor format
| Model | IPC321SR3-VSPF28 | IPC321SR3-VSPF40 | IPC321SR3-VSPF60 |
| Camera | |||
| Sensor | 1/3″, 1.3 megapixel, progressive scan CMOS | ||
| Shutter | Auto/Manual, 1/6~1/8000 s | ||
| Lens | 2.8 mm@F2.0
Angle of view(H): 96.5° |
4.0 mm@F2.0
Angle of view(H): 70.0° |
6.0 mm@F2.0
Angle of view(H): 45° |
| Day/Night | IR-cut filter with auto switch (ICR) | ||
| Min. Illumination | Colour: 0.02 Lux (F2.0, AGC ON)
0 Lux with IR |
||
| S/N | >50 dB | ||
| WDR | Supported | ||
| Video | |||
| Max. Resolution | 1280 × 960 | ||
| Video Compression | H.264, MJPEG | ||
| Frame Rate | 960P (1280*960): Max. 30 fps; 720P (1280*720): Max. 30 fps | ||
| 9:16 Corridor Mode | Supported | ||
| ROI | Supported | ||
| Video Streaming | Triple | ||
| OSD | Up to 8 OSDs | ||
| Privacy Mask | Up to 4 areas | ||
| Storage | |||
| Edge Storage | Micro SD, up to 128 GB | ||
| Network | |||
| Protocols | L2TP, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, Qos, NTP, FTP, HTTP, SNMP, SIP | ||
| Compatible Integration | ONVIF, API | ||
| Interface | |||
| Network | 10M/100M Base-TX Ethernet | ||
| General | |||
| Power | 12 V DC, or PoE (IEEE802.3 af) | ||
| Power consumption: Max 5.5W | |||
| Dimensions (Ø x H) | Φ108.5 x 81 mm (Ø4.28” x 3.2”) | ||
| Weight | 0.45 kg (0.99 lb) | ||
| Working Environment | -35°C ~ +60°C (-31°F ~ 140°F), Humidity ≤ 90% RH(non-condensing) | ||
| Vandal Resistant | IK10 | ||
| Ingress Protection | IP66 | ||
